How to Set Up Your Carl’s Place Pro Golf Enclosure Package (Step-by-Step Guide)

So, you’ve just ordered your Carl’s Place Pro Golf Enclosure Package from PlayBetter.com — congrats! You're one step closer to a commercial-grade golf simulator setup that turns your space into a world-class hitting bay. While the full instruction manual and video walkthrough are your go-to resources, we’ve created this guide to help you get set up faster—and without second-guessing yourself.

Before You Begin

Make sure you have:

• Your full enclosure kit (pipes, fittings, premium screen, ballistic-grade nylon, bungees, foam inserts, curtains, etc.)

• A large enough space cleared (check the size you selected!)

• At least one helper—this is a big enclosure and some steps require a second set of hands

• A rubber mallet, measuring tape, step ladder, and level

Instruction Manual & Walkthrough Video

Use the official Pro Series instruction manual and this full build video as references while working through each step.

Step 1: Assemble the Frame

🧱 Start from the bottom

Lay out the floor footprint using the labeled steel pipe sections. Use the corner and T-connectors to build the rectangular base.

📏 Build up

Add vertical poles to each corner, then connect the top bars to complete the frame structure. This gives you the sturdy skeleton of your Pro enclosure.

🔧 Tip

Use a rubber mallet or dead blow hammer to ensure all pipe connections are tight and flush—this keeps the frame square and rock solid.

Step 2: Attach the Impact Screen

🪝 Center the screen

Align the premium impact screen with the front of the frame. It should be flush with the sides and have even spacing on all edges.

💥 Bungee in place

Use the included ball bungees to secure the screen through the grommets. Begin at the top center, then alternate side-to-side working outward for balanced tension.

📌 Pro Tip

You want firm tension but not excessive pull—just enough to absorb ball strikes without puckering or overstretching.

Step 3: Install Side & Ceiling Panels

🖤 Hang the ballistic nylon

Drape the heavy-duty black side and ceiling panels over the top crossbars and attach via the hook-and-loop strips.

🔒 Fasten all seams

Use the integrated hook-and-loop flaps to secure corners and side panels together for full enclosure coverage.

💡 Lighting tip

These panels help control ambient light and boost image quality from your projector.

Step 4: Add the Curtain System

🎭 Mount the track

Your enclosure comes with a curtain track system for additional protection. Install the included hardware to the ceiling of the frame per the manual.

🧵 Hang the curtain

Slide the blackout curtain onto the track and ensure it extends fully across the hitting area. This acts as an extra buffer for stray shots.

🛡️ Curtain bonus

It also helps control light and sound, making your setup feel more immersive.

Step 5: Optional Accessories

🧩 Foam Insert Kit

Slides 18–20 in this presentation show how to install the foam panels around your screen’s border. These absorb mishits and provide a polished, finished edge.

🔙 Back Cover Kit

Complete the enclosure with a rear cover and optional piping to fully contain your simulator space—perfect for garages or well-lit rooms.

Step 6: Final Checks

✅ Make sure:

• All pipe connections are flush and secure

• The screen is evenly tensioned

• The nylon panels are properly aligned and sealed

• Foam, curtains, and back cover are installed (if applicable)

🎯 You’re now ready to finish your build with a hitting mat, projector, and launch monitor!

Video Walkthrough

Prefer visual instructions? Watch this full Carl’s Place Pro Enclosure build video for step-by-step footage of the entire setup process.

Need Help?

Our team is ready to assist if you have questions or need help optimizing your build. Reach out to us here or use the live chat on our site.

Let the games begin

You just built a simulator space worthy of a pro. Time to tee it up.
